The immersive sound processoris mainly used for immersivefixedinstallationssuchasimmersive pertormances, gyms,studios,multifunctionahalls,theme parks, museums, largestaircase classrooms, outdoorimmersivesoundconcerts,medium to largeconferencehalls,andotherapplicationscenarios.

In response to the sound quality loss causedbyncompression coding, an innovative method is adopted toperform model reverse learning on the high frequencyharmonics and middle and low frequency samplingvalues lost by the algorithm. We use the reverseconvolution of NPU to achieve precise playback of theoriginal sound and support multi-channel surround soundand immersive sound encoding. The implementationtechnology of multi-channel surround sound is based onVBAP (vector-base amplitude panning) and VBAP3D, andwe have added HOA (High-order algorithms) to supporthigh-precision sound field reproduction of 7-order64-channel.

Processing Channels

32

Input Routers

32 inputs routers

Output Routers

32 outputs routers

AES3 Inputs

Digital16ch

AES67 Inputs/outputs

Digital 32ch input/ 32ch output

Mic Inputs Processing

2 Mic Inputs, Gain,Phtom Power Switch

Spdif/Toslink InputsRCA Line Inputs

Digital 2ch

RCA Line Inputs

Analog 2ch

HDMI Inputs/outputs

Digital 2 x 8ch PCM Audio, 1xHDMI Video DirectOut

D-Sub Outputs

Analog 4 x 8ch

Input Processing

Gain, Azimuth,Elevation,Stereo Roll,Stereo Width

Out Processing

Gain, Azimuth,Elevation,Distance

Input Source Layout

Multi-Format Support,Virtual3D Visible

Output Speaker Layout

Customizable,Virtual3D Visible

HOA Processing

up to 7order multi-dimension-sound processing

Remote Control

Ehternet Remote Control



Audio Performance



Conversion Resolution

24-bit

Internal Sample Rate

48 kHz

Internal Data Path

32-bit Floating Piont

Product Processing Delay

1 Sample

Maximum Aavailable

<1ms
